PhilipsBrand: Philips Dynalite · Model: DDBC320-DALI
3-Line DALI-2 Controller with Ethernet
Twelve-unit DIN-rail controller with three DALI-2 lines, three feed-through relays and Ethernet for DyNet networks. It supports tunable-white (DT207/209) and RGBWAF drivers for offices, hotels and residential projects.
Technical Specifications
- Series
- DALI controllers
- Voltage
- 100-277V AC
- Current
- 0.5A supply
- Size
- 95 x 216 x 64 mm
- Weight
- 0.6 kg (packed)
- Material
- Polycarbonate DIN rail enclosure (12 unit)
- Mounting
- DIN rail
- Installation
- Indoor only
- Operating temperature
- -20 to 50°C ambient
- Outputs
- 3 x DALI-2 (DT207 / DT209 tunable white, RGBWAF); 3 x feed-through relay
- Protocols
- DyNet over RS-485 and Ethernet (TCP/IP, IPv4/IPv6)
- Certification
- DALI-2, CE, RCM, UL/cUL, FCC, ISED, UKCA, RoHS
Applications
- Offices
- Hotels
- Residential
Key Features
- 3 DALI-2 lines
- Ethernet port
- Tunable white / RGBWAF
- Driver runtime tracking
